Solar panel double sided adopts MBB design with more uniform crack stress distribution and higher reliability. Half cell reduces the heating of the module and improves the safety performance.
Dimension | 2094×1038×35mm |
Weight | 23.5kg |
No. of cells | 144 |
Rated Maximum Power | 455w |
Maximum Efficiency | 20.94% |
Junction Box | IP≥68, TÜV&UL |
Maximum System Voltage | DC1500 |
Operating Temperature | -40℃ to 85℃ |
Cable&Connector | 4mm2, EVO2 / EVO2 Compatible |
The product adopts an MBB high-efficiency PERC cell combined with half cutting technology. It can meet the rising demand for high efficiency and diversification of residential roofs, small industrial and commercial roofs, and large ground power stations.
Dimension | 1755×1038×35 |
Weight | 20kg |
No. of cells | 120 |
Rated Maximum Power | 375w |
Maximum Efficiency | 20.59% |
Junction Box | IP≥68, TÜV&UL |
Maximum System Voltage | DC1500 |
Operating Temperature | -40℃ to 85℃ |
Cable&Connector | 4mm2, EVO2 / EVO2 Compatible |
Full black solar panel adopts MBB design with a more uniform crack stress distribution and higher reliability. Half cell reduces the heating of the module and improves the safety performance. All black aesthetic BIPV, perfect fusion with architecture. Non-destructive cutting, greatly improved power and efficiency.
Dimension | 1776×1052×35 |
Weight | 20kg |
No. of cells | 120 |
Rated Maximum Power | 355w |
Maximum Efficiency | 19.01% |
Junction Box | IP≥68, TÜV&UL |
Maximum System Voltage | DC1500 |
Operating Temperature | -40℃ to 85℃ |
Cable&Connector | 4mm2, EVO2 / EVO2 Compatible |
The double glass solar panels can not only absorb energy from the front of the module but also absorb reflected light and scattered light from the back. It has better power generation capacity, lower temperature coefficient, smaller shielding loss and stronger mechanical load. Half cell reduces the risk of hot spots for high power modules and shows better power generation performance and reliability in system applications.
Dimension | 2094×1038×35mm |
Weight | 27kg |
No. of cells | 144 |
Rated Maximum Power | 450w |
Maximum Efficiency | 20.71% |
Junction Box | IP≥68, TÜV&UL |
Maximum System Voltage | DC1500 |
Operating Temperature | -40℃ to 85℃ |
Cable&Connector | 4mm2, EVO2 / EVO2 Compatible |
The product matches different installation conditions, takes into account high adaptability and high compatibility, with mature bracket and inverter solutions, and is specially designed for centralized ground power stations. Double-sided power generation technology can achieve a maximum of 30% backside gain.
Dimension | 1755×1038×35 |
Weight | 20kg |
No. of cells | 120 |
Rated Maximum Power | 370w |
Maximum Efficiency | 20.32% |
Junction Box | IP≥68, TÜV&UL |
Maximum System Voltage | DC1500 |
Operating Temperature | -40℃ to 85℃ |
Cable&Connector | 4mm2, EVO2 / EVO2 Compatible |
The product matches different installation conditions, takes into account high adaptability and high compatibility, with mature bracket and inverter solutions, and is specially designed for centralized ground power stations. Double-sided power generation technology can achieve a maximum of 30% backside gain.
Dimension | 2094×1038×35 |
Weight | 23.5kg |
No. of cells | 144 |
Rated Maximum Power | 445w |
Maximum Efficiency | 20.48% |
Junction Box | IP≥68, TÜV&UL |
Maximum System Voltage | DC1500 |
Operating Temperature | -40℃ to 85℃ |
Cable&Connector | 4mm2, EVO2 / EVO2 Compatible |
